Automatic Compact IRHD Tester – IRHD Compact III

Hardness tester digital, serial interface: The contact pressure and measuring time of IRHD Compact III are designed according to standards. IRHD Compact III also features embedded memory for saving up to 300 test results as well as optical and acoustic signals during the measuring process.

Get a Quote

Get a Service

Model No:	FZT-BR/ACIRHD-1012
Range of Application	hoses, tubes, O-rings, molded parts, norm plates and seals
Resolution:	0,1 IRHD M / 0,1 IRHD N
Standards	DIN ISO 48, ASTM D 1415, NFT 46-003,BS903 Part A 26

Description

Technical Data

Accessories

Application

If needed, the IRHD M or IRHD N indenters can easily be exchanged by the customer. For calibration, certification and evaluation of the instrument, only the measuring head needs to be returned to our Laboratory. Please use the original transport case when sending the device to Bareiss, while the test stand remains with the customer.

SIZE AND WEIGHT
METHOD
MICRO NORMAL

Dimensions LxWxH [mm] weights
Test stand 200 x 250 x 570 9,0 kg
Pick-up bracket IRHD N 100 x 100 x 150 1,3 kg
Measuring device IRHD N 70 x 90 x 150 1,9 kg
Measuring device IRHD M 160 x 100 x 140 1,4 kg

For further details download brochure below

IRHD_compact_lll_2018 FZ

Barofix - Bareiss North America - Testing Solutions Since 1954

Barofix
Centering device for a quick centring of O-rings of a cord diameter between 0,6 to 5,0 mm.Outer diameter up to 50 mm

Centrofix - Bareiss North America - Testing Solutions Since 1954

Centrofix
Centering device for quick centering of rubber tubes or hose.

DAkkS/DKD Calibration Certificate

When a measuring instrument is being calibrated, the given deviation is determined by various measurements versus standard references. A calibration certificate is then issued indicating the measuring results and the corresponding measurement uncertainties and the instrument is marked as calibrated.All documents together with the calibration certificate provide traceability of national standards.

DAkkS/DKD calibration certificate - Sample

Hardest the test and evaluation software program - Bareiss North America

Hardtest – the test – and evaluation software program
Applicable for all electronic Bareiss testing devices with a serial interface. The programme contains all functions which are necessary for a faultless processSoftware-Documentation

Reference Plates - Bareiss North America - Testing Solutions Since 1954

Reference Plates
Standard rubber blocks are used to ensure the metrological capability of the measuring device acc. to IRHD during the frequency of recalibration. The rubber blocks are embedded in a holder made of stainless steel.

We provide Ranges of applications. download the brochure from here

Ranges-of-Applications-and-Technical-Data_FZ_

Features & Benefits

User-Friendly: This automatic shore hardness tester is equipped with an electronic unit that can show user information, time, and method of measurement, and is equipped with various other configurations along with automatic measurement of time and range detection.
Range of Measurement: This Automatic hardness testing machine can measure the hardness of O rings, seals, rubbers, and plastics by making use of special measuring devices for which the fixtures can also be customized according to the sample that is to be tested.
Mechanism: The measuring devices have an easy plug-and-play solution with no complex mechanism. The measuring devices can easily be fastened by hand using the knurled nut and the electronic unit can easily detect the device once it is set up.

Complexity: Concave and convex samples can easily be tested for their shore hardness using the special measuring devices developed by Bareiss.
Special Features: The hysteresis function is available in Micro, IRHD and VLRH methods, providing a better understanding of the results for further analysis.
Integrable in an automatic production process.
